T-REX 470LM Dominator Combo

RH47E04X - T-REX 470LM Dominator Combo Align RH47E04X
Picture can be different from original item




The T-Rex 470L Dominator is the next evolutionary stage of the successful T-Rex 450 series and represents the logical further development of the T-Rex 450L Dominator.


Features


• New tail rotor belt drive
• New 470EFL main rotor head
• 380mm main rotor blades / 69mm tail rotor blades
• Progressive landing gear with 5° forward tilt
• DS450M / DS455M high voltage servos
• RCE-BL50X brushless speed controller
• Third bearing block for main rotor shaft
• New tail rotor blade holder
"M" version = rotor head and tail made of aluminum, servos with metal gears


Technical data


Length: 755mm
Height: 210mm
Width: 108mm
Main rotor blade length: 380mm
Main rotor diameter: 850mm
Tail rotor diameter: 181mm
Motor pinion: 11 teeth
Main gear: 121 teeth
Autorotation gear: 56 teeth
Tail rotor gear: 15 teeth
Gear ratio: 11:1:3.73
Weight (without battery): 860g


Content


• 1x T-REX 470LM Dominator Kit
• 2x 380mm carbon main rotor blade
• 2x 69mm carbon tail rotor blade
• 1x RCE-BL50X brushless ESC
• 1x 470MX brushless motor (1800KV)
• 3x DS450M digital servo
• 1x DS455M Digital Servo


Required for assembly


• 1x Flybarless System
• 1x transmitter (6-channel or more with helicopter system)
• 1x receiver (6-channel or more)
• 1x pitch gauge
• 1x 6S LiPo battery 1400-1900mAh
519,90 €
incl. Tax
plus Shipping
 Item in stock
Delivery time ca. 1 to 3 days*
Item number

RH47E04X

Manufacturer

Align

Packing weight2,0 Kg
EAN4713413998357
NewCondition
519.90EURInStock
AlignRH47E04X4713413998357
