T-REX 760X DOMINATOR Kit

RH76E04X - T-REX 760X DOMINATOR Kit Align RH76E04X
Picture can be different from original item



• New 700EFL Rotor Head, Super low CG
• New 760 Main Blades & 105 Tri-Tail Blades
• Narrow Body Design / Split-type of Main Frame
• Powerful 850MX 490KV Motor


Specifications


Length: 1390mm
Height: 360mm
Width: 195mm
Main Blade Length: 760mm
Main Rotor Diameter: 1702mm
Tail Rotor Diameter: 287mm
Motor Drive Gear: 12T
Main Drive Gear: 112T
Autorotation Tail Drive Gear: 102T
Tail Drive Gear: 23T
Drive Gear Ratio: 9.33:1:4.43
Weight (w/o Battery): Approx. 3750g


Content


• 1x T-REX 760X 3D Dominator Kit
• 2x 760 Carbon Fiber Blade
• 3x 105mm 3K Carbon Fiber Tail Blade
• 2x 760X 3D Main Rotor Holder Arm
• 2x 760X F3C Main Rotor Holder Arm
• 1x 850MX Brushless Motor (490KV)


Required for assembly


• 1x Transmitter (7-channel or more, helicopter system)
• 1x Receiver (7-channel or more)
• 2x 6S Li-Po 4500 ~ 5200mAh
• 1x Digital Pitch Gauge
• 1x Flybarless System
• 3x Swashplate Servo
• 1x Tail Servo
• 1x 120A-160A HV Brushless ESC
Before 1.167,99 €
999,99 €
incl. Tax
plus Shipping
 Item in stock.
Delivery time ca. 1 to 3 days*
Item number

RH76E04X

Manufacturer

Align

Packing weight4,2 Kg
EAN4713414007782
NewCondition
