800 OH-6 ARF Cayouse

The Roban OH6-8 is a true-to-scale 800 scale helicopter of the legendary OH-6 Cayuse (MD-500E). This ARF kit is aimed at advanced and professional modelers and combines realistic design, high-quality mechanics and impressive flight characteristics.

Technical data

• Length of the body: 1980 mm
• Length incl. rotors: 1960 mm
• Width: 590 mm
• Height: 645 mm
• Diameter of main rotor: 1660 mm
• Length of main rotor blades: 750 mm
• Fenstron diameter: 160 mm
• Length of tail rotor blades: 70 mm
• Diameter main shaft: 12 mm
• Diameter tail shaft: 5 mm
• Spindle diameter: 8 mm
• Number of main blades: 2
• Number of tail blades: 9
• Transmission ratio drive: 1:13.8:4.7
• Motor:* 1x 750MX 450KV brushless external rotor, 12S-capable
• Speed controller:* 1x 120A brushless, 12S-capable
• Servo:* 3x metal gear cyclic, 1x metal gear tail servo
• Battery:* 44.4 V 5000 mAh 35C
• Flight time: 8 minutes
• Take-off weight: 8000 g
• Flight stabilization:* 3-axis flybarless gyroscope
• Radio control:* min. 6 channels with pitch and throttle curves

Scope of delivery

• 1x 800 OH-6 ARF Cayouse
