800 AS-365 Coast Guard

Experience the legendary AS-365 Dauphin Coast Guard in RC scale: The Roban 800 AS-365 is a detailed ARF kit that impresses with its precise cockpit, Fenestron tail rotor and stable mechanics. Ideal for advanced to professional pilots.

Features

• Scale 1:6, length 1.76 m, main rotor 1.66 m - impressive size for spectacular flights
• Main rotor: 2 blades 750 mm each, Fenestron tail rotor with 9 blades
• Drive: 750MX 450KV brushless outrunner, 12S-capable, 120A ESC
• Servos: 3x metal gears (cyclic), 1x metal gear tail
• Flight stabilization: 3-axis flybarless gyro for precise handling
• Take-off weight: approx. 8 kg, flight time approx. 8 minutes
• Cockpit & lighting: Scale detail with instruments, seats and position lights

Technical specifications

• Length of the body: 1760 mm
• Length incl. rotors: 1960 mm
• Width: 360 mm
• Height: 570 mm
• Diameter of main rotor: 1660 mm
• Length of main rotor blades: 750 mm
• Fenstron diameter: 160 mm
• Length of tail rotor blades: 70 mm
• Diameter main shaft: 12 mm
• Diameter tail shaft: 5 mm
• Spindle diameter: 8 mm
• Number of main blades: 2
• Number of tail blades: 9
• Gear ratio: 1:13.8:4.7
• Motor:* 1x 750MX 450KV brushless external rotor, 12S-capable
• Speed controller:* 1x 120A brushless, 12S-capable
• Servo:* 3x metal gear cyclic, 1x metal gear tail servo
• Battery:* 44.4 V 5000 mAh 35C
• Flight time: 8 minutes
• Take-off weight: 8000 g
• Flight stabilization:* 3-axis flybarless gyroscope
• Radio control:* min. 6 channels with pitch and throttle curves

Scope of delivery

• Fuselage with mechanical base
• Main and tail rotors
• Cockpit, seats and instruments
• Lighting unit
• Landing gear and mounting kit
• Operating instructions

Still required

• Motor: 1x brushless
• ESC: 1x brushless, 12S-capable
• Flybarless system: 1x 3-axis gyro
• Battery: 1x 12S LiPo (44.4 V, 5000 mAh)
• Servos: 3x cyclic + 1x tail
• Remote control + receiver: 1 set (6+ channels)
